적용예시 : AMR, 교육용 등
Specification
Dimensions : 1,400 x 900 x 900mm (L x W x H) | ||
Payload : ≤ 30kg | Power : 24VDC | Bat. Capacity : 74Ah |
Max. Speed : ≤ 10km/h | Max. Torque : 10Nm | Min. turning rad : 0.5m |
Mechanics : McPherson strut 4W-Steering, Independent 4W-Driving | ||
적용예시 : 물류, 순찰 등
Specification
Dimensions : 2,800 x 1,800 x 900mm (L x W x H) | ||
Payload : ≤ 50kg | Power : 72VDC / 12VDC | Bat. Capacity : 45Ah |
Max. Speed : ≤ 40km/h | Max. Torque : 720Nm | Min. turning rad : 3m |
Mechanics : McPherson strut 4W-Steering, Independent 4W-Driving | ||
적용예시 : 항만, 건설현장 등
Specification
Dimensions : 15,000 x 3,000 x 2,300mm (L x W x H w/ unloaded) | ||
Payload : ≤ 70,000kg | Power : 600VAC / 24VDC | Bat. Capacity : 186KWh |
Max. Speed : ≤ 7km/h | Max. Torque : 720Nm | Min. turning rad : 13m |
Mechanics : 4W-Steering, 4W-Driving | ||
eADM™ Micro적용예시 : AMR, 교육용 등 | Specification
 | ||||||||||||
eADM™ Beta적용예시 : 물류, 순찰 등 | Specification
 | ||||||||||||
eADM™ HD적용예시 : 항만 ,건설현장 등 | Specification
 | ||||||||||||
